The DeepCool PX1000G is an ATX 3.0 power supply unit (PSU) with a capacity of 1000 watts and an 80 Plus Gold efficiency rating. This means it is designed to deliver high levels of power efficiently, with at least 87% energy efficiency at 20% load, 90% at 50% load, and 87% at 100% load.
Some special features of the DeepCool PX1000G include:
The 80 Plus Gold certification indicates that this PSU operates with high efficiency, resulting in less wasted energy and lower operating costs compared to less efficient PSUs.
With a maximum power output of 1000 watts, this PSU is perfect for high-end gaming PCs, workstations, or other systems that demand a lot of power.
Modular PSUs allow users to connect only the cables they need, which can help with cable management and airflow within the PC case, improving overall aesthetics and cooling performance.
DeepCool is known for using quality components in their PSUs, which can contribute to reliability and stability.
It likely includes multiple protection features such as over-voltage protection, under-voltage protection, over-current protection, short circuit protection, and over-power protection to safeguard the connected components from electrical damage.
Lastly, it comes with a 10-years manufacturer warranty.
| Specification | Value |
|---|---|
| Model | R-PXA00G-FC0B-UK |
| Type | ATX12V V3.0 |
| Product Dimensions | 150×160×86mm (W x L x H) |
| Efficiency certification | 80Plus GOLD/Cybenetics_Platinum |
| Fan Size | 135mm |
| Fan Bearing | FDB (Fluid Dynamic Bearing) |
| Topology | Active PFC + Half Bridge SRC LLC + DC to DC |
| Power Good Signal | 100-150ms |
| Hold Up Time | ≥16ms |
| Efficiency | ≥90% Under Typical Load(50% Loading) |
| Protection | OPP/OVP/SCP/OTP/OCP/UVP |
| Operation Temperature | 0 - 40℃ |
| Regulatory | CE/FCC/CCC/TUV-RH/RCM/EAC/CAN ICES-003(B)/NMB-003(B)/UKCA/BIS/KC |
| Erp Regulation | ErP 2014 |
| MTBF | 100,000 Hours |
| Wattage | 1000 Watt |
| Modular | FULLY MODULAR |
| PCIe Connector (6+2) | 3 |
| SATA Connector | 2 |
| Peripheral (4-Pin) | 1 |
| Warranty | 10 Years |
