The NeoECO Gold Modular 650W series is designed for enthusiasts seeking the best DIY-PC experience, delivering exceptional performance and stability. Let's explore the features and their explanations:
100% Full Modular Design:
Explanation: This feature allows users to use only the necessary cables, improving airflow and reducing clutter inside the PC. It simplifies cable management for a cleaner and more organized build. 80 PLUS Gold Certification:
Explanation: The series has been certified with 80 PLUS Gold, ensuring high energy efficiency. This certification reduces electricity bills by delivering power more efficiently to the system. Zero RPM Mode:
Explanation: The advanced thermal control includes a Zero RPM mode that turns off the fan at low loads, ensuring absolute silence during periods of lower power consumption. 120mm Silent Fan:
Explanation: The 120mm silent fan optimizes the balance between cooling and noise. It improves airflow and durability, providing a whisper-quiet experience with a long fan lifetime. PhaseWave Design:
Explanation: Incorporating a server-class Half-Bridge LLC design with synchronous rectification based on a DC-DC topology, this design enhances performance and stability, ensuring reliable power delivery to the system. CircuitShield Protection:
Explanation: The CircuitShield design offers a full suite of industrial-grade protections (OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO) to keep the system safe in various environments. High-Quality JP Capacitors:
Explanation: Japanese heavy-duty capacitors provide tight voltage regulation and low ripple and noise, maximizing the system's performance and stability. ATX 12V 2.4 Compatibility:
Explanation: Engineered according to the latest PSU guidelines and compatible with the newest CPU generation, ensuring compatibility with modern components. 7-Year Warranty:
Explanation: Backed by a 7-year warranty, the NeoECO Gold Modular series is designed to meet high standards of reliability, offering users peace of mind and long-term support. 28(18+10) pin MBU Socket:
Explanation: Providing a 28-pin MBU socket allows for compatibility with possible future MBU connectors, ensuring adaptability to evolving technology. In summary, the NeoECO Gold Modular 650W series offers a combination of modular design, energy efficiency, thermal control, and high-quality components, making it an ideal choice for professional modders and PC gamers who prioritize performance, reliability, and ease of use.
| Specifications | NE650G M |
|---|---|
| Parameter | Details |
| Product Name | NE650G M |
| Model Name | X7000A078-20 |
| Type | ATX 12V 2.4 |
| Modular | Fully |
| Dimension | 150(L) x 140(W) x 86(H) mm |
| Warranty | 7 years |
| Input Voltage | 100-240 VAC |
| Input Current | 10A MAX |
| Input Frequency Range | 50Hz-60Hz |
| PFC | Active PFC |
| Power Good Signal | 100-500ms |
| Efficiency | Up To 92% |
| Protection | OCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO |
| Output Capacity | 650W |
| Operation Temperature C | 0 ~ 40° |
| Regulatory | cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / UKCA / ICES |
| Fan | 120mm Silence Fan |
| Certifications | 80 Plus Gold |
| Connector | 1 x MB 24(20+4) Pin, 2 x 8(4+4) Pin EPS 12V, 4 x 8(6+2) Pin PCI-E, 8 x SATA, 3 x Molex, 1 x FDD |
| Net Weight | 1.30 kgs |
| Gross Weight | 2.50 kgs |
SMPS
| Brand | ANTEC |
| Stock Status | IN STOCK |
| Wattage | 650 WATT |
| Certification | 80 PLUS GOLD |
| Modular | FULLY MODULAR |
| PCle Connector (6+2) | 4 |
| SATA Connector | 8 |
| Peripheral (4-Pin) | 3 |
| Series | NEO ECO |
