The Eclipse G500A is a gaming PC case that emphasizes high airflow design and spacious interior to accommodate powerful gaming setups. Here's an expanded explanation of its features:
High Airflow Design: The G500A prioritizes airflow with both the front and top panels featuring Phanteks' Ultra-fine Performance Mesh design. This mesh design allows for optimal airflow while effectively filtering out dust, ensuring that components receive sufficient cooling without accumulating debris.
Extensive Radiator Support: This PC case offers extensive support for radiators, enabling users to install up to a 420mm radiator in the front and a 360mm radiator in the top. This capability allows for efficient cooling of high-performance CPUs and GPUs, unlocking their full potential for gaming and other demanding tasks.
Clean Cable Management and Flexible Storage Options: The G500A facilitates clean cable management with plenty of Velcro ties to secure cables neatly. Cover doors help conceal cables, maintaining a tidy interior. Additionally, the case provides multiple SSD brackets and stackable HDD bays, offering flexible storage options to accommodate various storage configurations.
Integrated D-RGB Lighting: The G500A features integrated D-RGB lighting, enhancing its aesthetic appeal. These lighting effects can be easily synchronized and controlled via compatible A/D-RGB equipped motherboards. The case comes with two LED strips pre-installed in the front and side panels, providing vibrant illumination.
Overall, the Eclipse G500A is designed to provide gamers with a combination of optimal airflow, extensive hardware support, clean cable management, and customizable lighting options, making it an ideal choice for building powerful gaming rigs while maintaining a clean and stylish aesthetic.
Eclipse G500A Black Specifications
| Specification | Details |
|---|---|
| Model Name | Eclipse G500A Black |
| Model No. | PH-EC500GA-DBK01A |
| Case Dimension | 500 x 240 x 515 mm / 19.7 x 9.4 x 20.3 in |
| Form Factor | Mid Tower |
| Materials | Steel Chassis, Tempered Glass |
| Motherboard Support | E-ATX (up to 280mm wide), ATX, micro-ATX, mini-ITX |
| Front IO | 1x USB 3.2 GEN 2 Type-C, 2x USB 3.0, Microphone/Headphone combo, Power Button, DRGB Mode Button, DRGB Colour Button |
| Connectors | Power Switch, D-RGB Expansion, D-RGB Third Party, D-RGB Motherboard, HD-Audio, USB 3.0, USB 3.2 GEN 2 Type-E, SATA Power |
| Side Window | Tempered Glass Side Panel |
| PCIe Slots | 7 |
| Vertical GPU | Yes, With Optional Vertical GPU Bracket |
| Internal 3.5'' bay | 10 (2x included) |
| Internal 2.5'' bay | 9 (2x included) |
| Total Fan Mounts | 7x 120mm / 7 x 140mm |
| Front Fan | 3 x 120mm / 3 x 140mm (3x140mm D-RGB included) |
| Top Fan | 3 x 120mm / 3 x 140mm |
| Rear Fan | 1 x 120mm / 1 x 140mm |
| Included Fans | 3 x M25-140 PWM D-RGB Black |
| Front Radiator | up to 360mm / up to 420 mm |
| Top Radiator | up to 360mm / up to 280 mm |
| Rear Radiator | 120 |
| GPU Length | 435mm / 17.2in |
| CPU Cooler Height | 185mm / 7.3in |
| PSU | 195 mm or 250 mm (4 HDD brackets / 2 HDD brackets used) |
| Front Panel fan thickness | 33mm for fan or radiator |
| Front 360 radiator thickness | 90mm thickness |
| Front 420 radiator | Maximum size: 142 x 475 x 90 mm |
| Top 360 radiator thickness | 70mm thickness |
| Package Dimension | 325 x 610 x 610 mm |
| Net Weight | 10.53 / 10.68 KG |
| Gross Weight | 12.70 / 12.85 KG |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Cabinet
| Brand | PHANTEKS |
| Stock Status | IN STOCK |
| Material | TEMPERED GLASS |
| Cabinet Size | MID-TOWER |
| Motherboard Size | E-ATX |
| LED | ARGB |
| Fan Size | 120 MM |
| Fan Size | 140 MM |
| Radiator Support | 280 MM |
| Radiator Support | 360 MM |
| Radiator Support | 420 MM |
