the features and capabilities of the NZXT C750 Bronze SMPS (Switched-Mode Power Supply), emphasizing its suitability for PC gamers seeking reliable and efficient power delivery:
Entry-Level High-Performance Power Supply:
The C750 Bronze is positioned as an entry-level power supply solution for gamers, offering high-performance capabilities to support gaming systems effectively. High Efficiency:
Achieves up to 88% efficiency at 50% load, exceeding the 80 Plus Bronze standards. This high efficiency helps reduce energy waste and heat generation, contributing to a more sustainable and cooler-running system. Quiet and Long-Lasting Cooling:
Equipped with a 120mm fluid dynamic bearing fan, the power supply ensures low-noise performance while also providing enhanced longevity. This feature helps maintain quieter operation during gaming sessions. Consistent Power Delivery to GPUs:
Utilizes DC-to-DC conversion technology to ensure consistent power delivery to GPUs, supporting graphics cards with up to 220W of power consumption. This feature is particularly beneficial for high-performance GPUs like the RTX 3070. Safety Protections:
Tested for safety at temperatures of up to 40°C, the power supply includes over-temperature and over-current protections. These safety features help safeguard the system components from potential damage due to power fluctuations or overheating. Durable and Sleek Design:
The main PSU cables are nylon-sleeved for durability, offering protection against wear and tear. Additionally, the matte black finish of the cables complements any build aesthetics, ensuring a sleek and cohesive look for the gaming setup. Overall, the NZXT C750 Bronze SMPS provides gamers with a reliable, efficient, and quiet power supply solution, featuring advanced technologies and safety measures to support high-performance gaming systems while maintaining longevity and aesthetics.
Specifications
| Specification | Details |
|---|---|
| Model | C750 Bronze |
| Model Number | PA-7B2BB |
| Output Connector(s) | |
| 24-pin ATX Power | 1 |
| 4+4-pin CPU power | 2 |
| 6+2-pin PCIe power | 2 |
| SATA Power | 4 |
| Peripherals | 4 |
| Energy Efficiency | |
| Rating | 80 Plus Bronze |
| 10% loading | 86.2% @115Vac |
| 20% loading | 88.97% @115Vac |
| 50% loading | 88.7% @115Vac |
| 100% loading | 83.2% @115Vac |
| Cable Specs | |
| 24-pin ATX power | 600mm, Nylon sleeving |
| 4+4-pin CPU power | 700mm, Nylon sleeving |
| 6+2-pin PCIe power | 650 + 150mm, Nylon sleeving |
| SATA power | 500 + 150 mm |
| Peripherals | 500 + 150 mm |
| Fan Specs | |
| Dimensions | 120 x 120 x 25 (mm) |
| Speed | 2400 ±10% RPM |
| Airflow | 64.4 CFM (Tpy.) |
| Noise | 39.92 dBA max |
| Bearing | FDB (Fluid Dynamic Bearing) |
| AC Input Rating | |
| 100 - 240Vac | 10A-5A 50Hz-60Hz |
| DC Output Rating | |
| +3.3V | 20A (120W) |
| +5V | 20A (120W) |
| +12V | 62.5A (750W) |
| -12V | 0.3A (3.6W) |
| 5Vsb | 2.5A (12.5W) |
| Total | 750W |
| Operation | |
| PF Correction | Active@0.96 |
| MTBF | 100,000 hours |
| Operation Temperature | 0 to 40°C |
| General | |
| Dimensions (W x L x H) | 150 x 140 x 86mm |
| Material(s) | Steel, PCB and Plastic |
| Compliance Standard | ATX12V v2.53 / EPS12V v2.92 |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
SMPS
| Brand | NZXT |
| Stock Status | IN STOCK |
| Wattage | 750 WATT |
| Certification | 80 PLUS BRONZE |
| Modular | SEMI MODULAR |
| PCle Connector (6+2) | 6 |
| SATA Connector | 6 |
| Peripheral (4-Pin) | 3 |
| Series | POWER SERIES |
