i9-14900KF Desktop Processor: This refers to a specific model of Intel's desktop processor lineup. In this case, it's the i9-14900KF.
Compatible with Intel 600-series (with potential BIOS update) and 700-series chipset-based motherboards: This means that the i9-14900KF processor can work with motherboards that have either Intel 600-series or 700-series chipsets. However, compatibility might require a BIOS update on the motherboard. BIOS updates are software patches that enable compatibility with newer hardware.
Up to 6.0 GHz unlocked: This indicates the maximum clock speed (frequency) the processor can achieve when overclocked. Overclocking is a process of increasing the clock speed of a component beyond its factory settings to boost performance. The "unlocked" part suggests that the processor multiplier is not locked, allowing users to adjust it for overclocking purposes.
36MB Cache: Cache memory is high-speed memory located directly on the processor die. It's used to store frequently accessed data and instructions, allowing the processor to access them quickly, which can improve overall system performance. The 36MB cache size indicates the total amount of cache memory available on the processor.
So, in summary, the i9-14900KF is a high-performance desktop processor compatible with certain Intel 600-series and 700-series motherboards, potentially requiring a BIOS update for compatibility. It has a maximum unlocked clock speed of 6.0 GHz and a generous 36MB cache, which contributes to its performance capabilities.
i9-14900KF Processor Specifications
| Specification | Details |
|---|---|
| Model | i9-14900KF |
| Product Collection | Intel® Core™ i9 Processors (14th gen) |
| Code Name | Products formerly RAPTOR LAKE |
| Vertical Segment | Desktop |
| Lithography | Intel 7 |
| Use Conditions | PC/Client/Tablet |
| Total Cores | 24 |
| # of Performance-cores | 8 |
| # of Efficient-cores | 16 |
| Total Threads | 32 |
| Max Turbo Frequency | 6 GHz |
| Intel® Thermal Velocity Boost Frequency | 6 GHz |
| Intel® Turbo Boost Max Technology 3.0 Frequency | 5.8 GHz |
| Performance-core Max Turbo Frequency | 5.6 GHz |
| Efficient-core Max Turbo Frequency | 4.4 GHz |
| Performance-core Base Frequency | 3.2 GHz |
| Efficient-core Base Frequency | 2.4 GHz |
| Cache | 36 MB Intel® Smart Cache |
| Total L2 Cache | 32 MB |
| Processor Base Power | 125 W |
| Maximum Turbo Power | 253 W |
| Supplemental Information | |
| Marketing Status | Launched |
| Launch Date | Q4'23 |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 192 GB |
| Memory Types | Up to DDR5 5600 MT/s Up to DDR4 3200 MT/s |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 89.6 GB/s |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4.0 |
| Max # of DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations | Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | FCLGA1700 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2020A |
| TJUNCTION | 100°C |
| Package Size | 45.0 mm x 37.5 mm |
| Advanced Technologies | |
| Intel® Gaussian & Neural Accelerator | 3.0 |
| Intel® Thread Director | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Adaptive Boost Technology | Yes |
| Intel® Thermal Velocity Boost | Yes |
| Intel® Turbo Boost Max Technology 3.0 | Yes |
| Intel® Turbo Boost Technology 2.0 | Yes |
| Intel® Hyper-Threading Technology | Yes |
| Intel® 64 | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Intel® Standard Manageability (ISM) | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® OS Guard | Yes |
| Execute Disable Bit | Yes |
| Intel® Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel® Virtualization Technology (VT-x) | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® VT-x with Extended Page Tables (EPT) | Yes |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Bx8071514900kf
| Brand | INTEL |
| Stock Status | IN STOCK |
| Memory Type | DDR4 |
| Memory Type | DDR5 |
| Socket Support | LGA 1700 |
| CPU | CORE I9 |
| Cores | 24 |
| Series | 14TH GEN |
| Max Memory Support | 192 GB |
| Integrated Graphics | NO |
