The Intel Core i5-14600KF is a robust desktop processor designed to deliver high performance across various computing tasks. Let's delve into its features:
Core Configuration: This processor boasts a total of 14 cores, comprising 6 Performance cores (P-cores) and 8 Efficiency cores (E-cores). This combination ensures efficient multitasking and performance optimization for a wide range of applications.
Thread Count: With support for 20 threads, the processor can handle multiple tasks simultaneously, facilitating smooth multitasking and responsiveness.
Turbo Boost Max Technology 3.0: This technology dynamically boosts the frequency of the processor cores to maximize performance when needed. It identifies the fastest cores on the processor and directs demanding workloads to them, enhancing single-threaded performance.
PCIe Support: The processor supports both PCIe 5.0 and PCIe 4.0, enabling high-speed connectivity for peripherals such as graphics cards, storage devices, and networking cards. PCIe 5.0 offers even faster data transfer speeds compared to PCIe 4.0, ensuring smooth data flow and responsiveness.
Memory Support: The processor is compatible with both DDR4 and DDR5 memory types. This flexibility allows users to choose the memory configuration that best suits their needs, whether it's DDR4 for cost-effectiveness or DDR5 for higher performance and efficiency.
Overall, the Intel Core i5-14600KF desktop processor offers a compelling combination of high core count, thread support, turbo boost technology, PCIe connectivity, and memory flexibility. It is well-suited for a variety of computing tasks, including gaming, content creation, and productivity applications.
Intel Core i5-14600KF Desktop Processor Specifications
| Specification | Details |
|---|---|
| Model | i5-14600KF |
| Product Collection | Intel® Core™ i5 Processors (14th gen) |
| Code Name | Products formerly RAPTOR LAKE |
| Vertical Segment | Desktop |
| Lithography | Intel 7 |
| Use Conditions | PC/Client/Tablet |
| CPU Specifications | |
| Total Cores | 14 |
| # of Performance-cores | 6 |
| # of Efficient-cores | 8 |
| Total Threads | 20 |
| Max Turbo Frequency | 5.3 GHz |
| Performance-core Max Turbo Frequency | 5.3 GHz |
| Efficient-core Max Turbo Frequency | 4 GHz |
| Performance-core Base Frequency | 3.5 GHz |
| Efficient-core Base Frequency | 2.6 GHz |
| Cache | 24 MB Intel® Smart Cache |
| Total L2 Cache | 20 MB |
| Processor Base Power | 125 W |
| Maximum Turbo Power | 181 W |
| Supplemental Information | |
| Marketing Status | Launched |
| Launch Date | Q4'23 |
| Embedded Options Available | No |
| Memory Specifications | |
| Max Memory Size (dependent on memory type) | 192 GB |
| Memory Types | Up to DDR5 5600 MT/s |
| Up to DDR4 3200 MT/s | |
| Max # of Memory Channels | 2 |
| Max Memory Bandwidth | 89.6 GB/s |
| Expansion Options | |
| Direct Media Interface (DMI) Revision | 4.0 |
| Max # of DMI Lanes | 8 |
| Scalability | 1S Only |
| PCI Express Revision | 5.0 and 4.0 |
| PCI Express Configurations ‡ | Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes | 20 |
| Package Specifications | |
| Sockets Supported | FCLGA1700 |
| Max CPU Configuration | 1 |
| Thermal Solution Specification | PCG 2020A |
| TJUNCTION | 100°C |
| Package Size | 45.0 mm x 37.5 mm |
| Advanced Technologies | |
| Intel® Gaussian & Neural Accelerator | 3.0 |
| Intel® Thread Director | Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes |
| Intel® Speed Shift Technology | Yes |
| Intel® Turbo Boost Technology ‡ | 2.0 |
| Intel® Hyper-Threading Technology ‡ | Yes |
| Intel® 64 ‡ | Yes |
| Instruction Set | 64-bit |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States | Yes |
| Enhanced Intel SpeedStep® Technology | Yes |
| Thermal Monitoring Technologies | Yes |
| Intel® Volume Management Device (VMD) | Yes |
| Security & Reliability | |
| Intel® Standard Manageability (ISM) ‡ | Yes |
| Intel® Control-Flow Enforcement Technology | Yes |
| Intel® AES New Instructions | Yes |
| Secure Key | Yes |
| Intel® OS Guard | Yes |
| Execute Disable Bit ‡ | Yes |
| Intel® Boot Guard | Yes |
| Mode-based Execute Control (MBEC) | Yes |
| Intel® Virtualization Technology (VT-x) ‡ | Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
| Warranty | |
| Warranty | 3 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Bx8071514600kf
| Brand | INTEL |
| Stock Status | IN STOCK |
| Memory Type | DDR4 |
| Memory Type | DDR5 |
| Socket Support | LGA 1700 |
| CPU | CORE I5 |
| Cores | 14 |
| Series | 14TH GEN |
| Max Memory Support | 192 GB |
| Integrated Graphics | NO |
