The Lian Li O11D EVO XL Upright GPU Bracket Kit is specifically crafted for accommodating large GPUs like the 40 series GPUs. It introduces a new mounting angle for the GPU, offering an enhanced chimney-style configuration to optimize airflow within the chassis.
Features:
Upright Graphics Card Accessories for O11D EVO XL: This accessory kit enables the installation of the graphics card in an upright position, providing better cooling performance within the O11D EVO XL case.
New Mounting Angle for GPU: The kit introduces a new angle for mounting the GPU, facilitating an unrestricted chimney-style airflow configuration. This design is particularly advantageous for cooling large GPUs effectively.
Optimized for Direct Cooling: By positioning the GPU upright next to the motherboard, the bracket promotes chimney-style airflow. Additionally, the option to mount intake fans behind the GPU further enhances temperature control for the graphics card.
Simple Installation: Mounting the upright GPU kit is straightforward, as it directly attaches to the side fan bracket of the case. This simplicity streamlines the installation process for users.
Two Direction Installation: The bracket allows for the GPU to be flipped along with the side bracket. This flexibility enables users to choose whether they want the GPU ports positioned at the top or bottom of the case.
GPU IO Facing Upwards: It is recommended to mount the GPU with a 600mm PCIe riser cable for optimal performance and compatibility with the bracket.
GPU IO Facing Downwards: For this orientation, it is advised to mount the GPU with a 900mm PCIe riser cable to ensure proper functionality and fit within the case.
O11D EVO XL Upright GPU Bracket Specification
| Specification | Details |
|---|---|
| PRODUCT NAME | O11D EVO XL Upright GPU Bracket |
| MODEL | O11DEXL-1X |
| COLOR | Black |
| BRACKET DIMENSION | Mounting frame: 93.5mm(L) x 145mm(D) x 80mm(H) Support frame: 87.5mm(L) x 152mm(D) x 25mm(H) |
| MATERIAL | 1mm STEEL |
| EXPANSION SLOT | 4 slots |
| GPU COMPATIBILITY | Length: 358 mm Thickness: 80 mm Width: 150 mm |
| Warranty | 1 Year |
| Note | *** Features, Price, Specifications are subject to change without notice. |
