| Specification |
Description |
| Essentials |
|
| Product Collection |
13th Generation Intel® Core™ i5 Processors |
| Code Name |
Products formerly Raptor Lake |
| Vertical Segment |
Desktop |
| Processor Number |
i5-13600KF |
| Lithography |
Intel 7 |
| CPU Specifications |
|
| Total Cores |
14 |
| # of Performance-cores |
6 |
| # of Efficient-cores |
8 |
| Total Threads |
20 |
| Max Turbo Frequency |
5.30 GHz |
| Performance-core Max Turbo Frequency |
5.10 GHz |
| Efficient-core Max Turbo Frequency |
3.90 GHz |
| Performance-core Base Frequency |
3.50 GHz |
| Efficient-core Base Frequency |
2.60 GHz |
| Cache |
24 MB Intel® Smart Cache |
| Total L2 Cache |
20 MB |
| Processor Base Power |
125 W |
| Maximum Turbo Power |
181 W |
| Supplemental Information |
|
| Embedded Options Available |
No |
| Memory Specifications |
|
| Max Memory Size (dependent on memory type) |
192 GB |
| Memory Types |
Up to DDR5 5600 MT/s, Up to DDR4 3200 MT/s |
| Max # of Memory Channels |
2 |
| Max Memory Bandwidth |
89.6 GB/s |
| Expansion Options |
|
| Direct Media Interface (DMI) Revision |
4.0 |
| Max # of DMI Lanes |
8 |
| Scalability |
1S Only |
| PCI Express Revision |
5.0 and 4.0 |
| PCI Express Configurations |
Up to 1x16+4, 2x8+4 |
| Max # of PCI Express Lanes |
20 |
| Package Specifications |
|
| Sockets Supported |
FCLGA1700 |
| Max CPU Configuration |
1 |
| TJUNCTION |
100°C |
| Advanced Technologies |
|
| Intel® Gaussian & Neural Accelerator |
3.0 |
| Intel® Thread Director |
Yes |
| Intel® Deep Learning Boost (Intel® DL Boost) |
Yes |
| Intel® Speed Shift Technology |
Yes |
| Intel® Turbo Boost Max Technology 3.0 ‡ |
No |
| Intel® Turbo Boost Technology ‡ |
2.0 |
| Intel® Hyper-Threading Technology ‡ |
Yes |
| Intel® 64 ‡ |
Yes |
| Instruction Set |
64-bit |
| Instruction Set Extensions |
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 |
| Idle States |
Yes |
| Enhanced Intel SpeedStep® Technology |
Yes |
| Thermal Monitoring Technologies |
Yes |
| Intel® Volume Management Device (VMD) |
Yes |
| Security & Reliability |
|
| Intel® Standard Manageability (ISM) ‡ |
Yes |
| Intel® Control-Flow Enforcement Technology |
Yes |
| Intel® AES New Instructions |
Yes |
| Secure Key |
Yes |
| Intel® OS Guard |
Yes |
| Execute Disable Bit ‡ |
Yes |
| Intel® Boot Guard |
Yes |
| Mode-based Execute Control (MBEC) |
Yes |
| Intel® Virtualization Technology (VT-x) ‡ |
Yes |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ |
Yes |
| Intel® VT-x with Extended Page Tables (EPT) ‡ |
Yes |
| Warranty |
3 Years |
| Note |
*** Features, Price, Specifications are subject to change without notice. |
