The Cooler Master CMP 520 is a mid-tower ATX cabinet designed to house your PC components efficiently while offering good airflow and a sleek design. Here are some features you might find in the CMP 520:
The case is designed to accommodate ATX motherboards, providing enough space for standard ATX components.
Mid-tower cases strike a balance between space efficiency and component compatibility, making them suitable for many gaming or workstation builds.
It comes with several fan mounting points and possibly included fans, ensuring adequate airflow to keep your components cool during operation. Look out for features like mesh panels or vents to aid in cooling.
A good case like CMP 520 Cabinet offers options for routing and managing cables to keep your build clean and tidy. Look for features like routing holes, tie-down points, and ample space behind the motherboard tray for cable management.
It has provisions for mounting both HDDs and SSDs, with tool-less drive bays for easy installation and removal.
Expect to find USB ports (including USB 3.0), audio jacks, and possibly other ports conveniently located on the front panel for easy access.
Cooler Master is known for producing sturdy cases with good build quality. The CMP 520 should be no exception, featuring durable materials and solid construction.
The design of the case, including its exterior and interior layout, is likely optimized for both functionality and aesthetics, offering a sleek and modern look.
| Specifications | Value |
|---|---|
| Model | CP520-KGNN-S00 |
| Exterior Color | Black |
| Materials - Exterior | Steel, Plastic |
| Materials - Left Side Panel | Tempered Glass |
| Dimensions (L x W x H) | 439 x 204 x 463mm (Incl. Protrusions), 432 x 204 x 448mm (Excl. Protrusions) |
| Volume | 43.34L (Exlc. Protrusions) |
| Motherboard Support | Mini ITX, Micro ATX, ATX |
| Expansion Slots | 7 |
| 2.5" / 3.5" Drive Bays (combo) | 2 |
| 2.5" Drive Bays | 2 |
| I/O Panel | 1x USB 3.2 Gen 1 Type-A, 1x USB 2.0, 1x 3.5mm Headset Jack (Audio+Mic) |
| ARGB Controller | CF120P (integrated with fan) or M/B |
| Pre-installed Fans - Front | 1x CF120P ARGB + 2x CF120S ARGB |
| Fan Support - Top | 2x 120mm, 2x 140mm |
| Fan Support - Front | 3x 120mm, 2x 140mm |
| Fan Support - Rear | 1x 120mm |
| Radiator Support - Top | 120 / 240mm* (*RAM height below 35mm) |
| Radiator Support - Front | 120mm, 140mm, 240mm, 280mm |
| Radiator Support - Rear | 120mm |
| Clearance - CPU Cooler | 161mm |
| Clearance - PSU | 160mm |
| Clearance - GFX | 350mm (w/o front fans & radiator) |
| Cable Routing | 18.5mm |
| Dust Filters | Top, Bottom |
| Power Supply Support | Bottom Mount, ATX |
| Series | CMP Series |
| Size | Mid Tower |
| Warranty | 2 Years |
Black
| Brand | COOLER MASTER |
| Stock Status | IN STOCK |
| Material | ALLOY STEEL |
| Cabinet Size | MID-TOWER |
| Motherboard Size | ATX |
| Motherboard Size | MATX |
| Motherboard Size | M-ITX |
| LED | ARGB |
| Fan Size | 120 MM |
| Fan Size | 140 MM |
| Radiator Support | 120 MM |
| Radiator Support | 140 MM |
| Radiator Support | 240 MM |
| Radiator Support | 280 MM |
