The Thermaltake Smart BX1 550W SMPS is a power supply unit (PSU) designed to deliver reliable and efficient power to your PC components. Let's delve into its features:
80 PLUS Bronze Certification: This PSU is built to deliver 80 PLUS Bronze certification with 88% power efficiency. It ensures that the PSU operates efficiently, converting more power from the wall outlet into usable power for your computer components.
Hydraulic Bearing Fan: Equipped with a 120mm hydraulic bearing fan, the Smart BX1 series ensures superior cooling performance while maintaining near-silent operation. The intelligent RPM controls help regulate fan speed for optimal cooling.
Japanese Main Capacitors and Premium Components: Constructed with Japanese main capacitors and other premium components, this PSU delivers a continuous and stable power output at 40℃. It ensures reliable performance and longevity.
5-Year Warranty: The Smart BX1 series comes with an ample 5-year warranty, providing users with peace of mind and assurance of quality and reliability.
Low Ripple Noise: The PSU maintains low ripple noise levels, ensuring stable operation and reliability even under heavy loads. This feature is crucial for maintaining the performance and longevity of high-end components like graphics cards.
High Amperage Single +12V Rail: With a powerful single +12V rail, the PSU ensures a stable and reliable power supply to all PC components, supporting their optimal performance.
Multiple Connectors with Sleeve Cabling: The PSU comes with soft black cables featuring sleeve cabling, making cable installation easy while ensuring optimal voltages to power the system.
80 PLUS Gold Certified and Intel C6/C7 States Ready: The Smart BX1 series is 80 PLUS Bronze certified, offering high energy efficiency of up to 88%. It's also optimized to work with all generations of Intel processors, achieving maximum energy savings and compatibility with Intel C6/C7 states.
Overall, the Thermaltake Smart BX1 550W SMPS offers a balance of efficiency, reliability, and performance, making it an ideal choice for value-oriented users seeking a high-quality power supply with the latest features.
Smart BX1 550W Power Supply Specifications
| Specification | Details |
|---|---|
| Model | Smart BX1 550W |
| P/N | PS-SPD-0550NNSABD-1 |
| Watts | 550W |
| RGB Fan | No |
| Form Factor | ATX |
| Model | SPD-550AH2NKB |
| Type | ATX 12V v2.3 and EPS v2.92 |
| Max. Output Capacity | 550W |
| Color | Black |
| Dimension (W / H / D) | 150mm(W) x 86mm(H) x 140mm(D) |
| PFC (Power Factor Correction) | Active PFC |
| Power Good Signal | 100-500 msec |
| Hold Up Time | > 16msec at 70% of full load |
| Input Current | 10A max. |
| Input Frequency Range | 50Hz - 60Hz |
| Input Voltage | 100V – 240V~ |
| Operating Temperature | 5°C to + 40°C |
| Operating Humidity | 20% to 85%, non-condensing |
| Storage Temperature | -40°C to + 55°C |
| Storage Humidity | 10% to 95%, non-condensing |
| Cooling System | 12cm Hydraulic bearing fan |
| Efficiency | Meet 80 PLUS® Bronze at 115Vac input. |
| MTBF | 100,000 hrs minimum |
| Safety Approval | CE/CB/TUV/ UL/ FCC/ BSMI |
| PCI-E 6+2pin | 2 |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
SMPS
| Brand | THERMALTAKE |
| Stock Status | IN STOCK |
| Wattage | 550 WATT |
| Certification | 80 PLUS BRONZE |
| Modular | NON MODULAR |
| PCle Connector (6+2) | 2 |
| SATA Connector | 6 |
| Peripheral (4-Pin) | 4 |
| Series | SMART SERIES |
