| Specification | Details |
|---|---|
| Model Number | PH-XT523V1-DWT01 |
| Product Dimension (DxWxH) | 440x230x500mm |
| Form Factor | Mid Tower |
| Motherboard Support | ATX, Micro-ATX, Mini-IT, E-ATX (280mm without GPU support bracket) |
| Materials | Steel Chassis (Tempered Glass) |
| Front I/O | 1x USB-C 3.2 GEN 2 2x USB 3.0 Microphone/Headphone Combo Reset Button Power Button D-RGB Color button D-RGB Mode button |
| Connectors | Power Switch Reset Switch HD-audio USB 3.0 USB 3.2 GEN 2 Type-E D-RGB expansion D-RGB Motherboard |
| Expansion | PCI Slots: 7 Internal 3.5" Bay: 2 (2x included) Internal 2.5" Bay: 5 (5x included) |
| Fans & Radiators | Top Fan: 3 x 120mm / 2 x 140mm Right Side Fan: 2 x 120mm Rear Fan: 1 x 120mm / 1 x 140mm Midplate Fan: 3 x 120mm Top Radiator: up to 360mm Right Side Radiator: up to 240mm (only with Vertical GPU) Rear Radiator: 120mm |
| Clearances | GPU Length: 415mm GPU Width: 184mm CPU Cooler Height: 184mm Power Supply: 270mm Top 360 radiator: 415 x 138 x 60mm Side 240 radiator: 305 x 120 x 62mm (only with Vertical GPU) Rear Radiator: 120mm |
| Warranty | 5 Years |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Cabinet
| Brand | PHANTEKS |
| Stock Status | IN STOCK |
| Material | TEMPERED GLASS |
| Material | STAINLESS STEEL |
| Cabinet Size | MID-TOWER |
| Motherboard Size | ATX |
| Motherboard Size | E-ATX |
| Motherboard Size | ITX |
| Motherboard Size | MATX |
| Motherboard Size | M-ITX |
| LED | RGB |
| Fan Size | 120 MM |
| Fan Size | 140 MM |
| Radiator Support | 120 MM |
| Radiator Support | 140 MM |
| Radiator Support | 240 MM |
| Radiator Support | 280 MM |
| Radiator Support | 360 MM |
| Shipping Cost |
|
| Shop Location |
