ASUS TUF GAMING A620M-PLUS Features
Advanced AMD AM5 Socket
The ASUS TUF GAMING A620M-PLUS motherboard is designed to support the latest AMD Ryzen™ 7000 Series Desktop Processors, leveraging the cutting-edge AMD AM5 socket. This ensures top-tier performance and compatibility with the most recent advancements in AMD processor technology, providing users with a future-proof platform for their computing needs.
Enhanced Power Solution
Built with durability and performance in mind, the motherboard features a robust six-layer PCB. The inclusion of alloy chokes and military-grade TUF components guarantees longevity and stability, even under intense computing loads. The DIGI+ VRM enhances voltage regulation, ensuring efficient and stable power delivery to the CPU and other critical components.
ASUS OptiMem II Technology
ASUS OptiMem II technology significantly enhances memory performance by optimizing trace layouts and grounding paths. This careful routing preserves signal integrity, allowing for improved memory stability and overclocking potential. The result is faster, more reliable memory performance, essential for high-speed computing and gaming.
Comprehensive Cooling Solutions
Effective cooling is critical for maintaining system performance and longevity. The TUF GAMING A620M-PLUS features an enhanced VRM heatsink and a dedicated PCH heatsink to manage heat dissipation efficiently. Hybrid fan headers and Fan Xpert 2+ technology offer flexible and intelligent cooling solutions, ensuring your system remains cool and quiet, even during peak performance.
Ultrafast Connectivity
Stay ahead with ultrafast connectivity options. The motherboard supports PCIe 4.0 for rapid data transfer speeds and includes dual M.2 slots for high-speed NVMe SSDs. USB 3.2 Gen 1 Type-A and front-panel USB 3.2 Gen 1 Type-C® ports provide versatile connectivity options for modern peripherals and devices, ensuring seamless data transfers and device compatibility.
Optimized for Online Gaming
For gamers, the TUF GAMING A620M-PLUS offers robust networking capabilities with Realtek 2.5Gb Ethernet. This high-speed connection reduces latency and enhances data throughput, providing a competitive edge in online gaming. The TUF LANGuard technology further protects the LAN port, ensuring a reliable and secure network connection.
Aura Sync RGB Lighting
Personalize your setup with Aura Sync RGB lighting. The motherboard includes onboard addressable Gen 2 headers, allowing you to connect RGB LED strips and other Aura Sync-capable hardware. This enables synchronized lighting effects, creating a visually stunning and cohesive gaming environment.
Two-Way AI Noise Cancelation
Ensure clear communication during gaming sessions or video conferences with the two-way AI noise cancelation feature. This technology reduces background noise from both the microphone and audio output, providing crystal-clear audio for more immersive and distraction-free interactions.
Conclusion
The ASUS TUF GAMING A620M-PLUS motherboard combines advanced technology, robust construction, and comprehensive features to deliver a reliable and high-performance platform for gamers and power users. From its future-proof AMD AM5 socket and enhanced power delivery to its extensive connectivity options and intelligent cooling solutions, this motherboard is designed to meet the demands of modern computing with ease and efficiency.
| Specifications Details | __parsed_extra | |
|---|---|---|
| Model Number | TUF GAMING A620M-PLUS | |
| CPU | AMD Socket AM5 for AMD Ryzen™ 7000 Series Desktop Processors | |
| Chipset |
|
|
| Memory 4 x DIMM slots | Max. 128GB, DDR5 6400+(OC)/ 6200(OC)/ 6000(OC)/ 5800(OC)/ 5600(OC)/ 5400(OC)/ 5200/ 5000/ 4800, ECC and Non-ECC, Un-buffered Memory* Dual Channel Memory Architecture Supports AMD Extended Profiles for Overclocking (EXPO™) OptiMem II | |
| Graphics | 2 x DisplayPort** 1 x HDMI™ port*** * Graphics specifications may vary between CPU types. Please refer to AMD CPU specifications. ** Support max. 8K@60Hz as specified in DisplayPort 1.4. *** Supports 4K@60Hz as specified in HDMI 2.1. | |
| Expansion Slots | AMD Ryzen™ 7000 Series Desktop Processors* 1 x PCIe 4.0 x16 slot AMD A620 Chipset 2 x PCIe 3.0 x1 slots * Please check the PCIe bifurcation table on the support site | |
| Storage Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* AMD Ryzen™ 7000 Series Desktop Processors M.2_1 slot (Key M) | type 2242/2260/2280 (supports PCIe 4.0 x4 mode) M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 4.0 x4 mode) AMD A620 Chipset 4 x SATA 6Gb/s ports * AMD RAIDXpert2 Technology supports both PCIe RAID 0/1/10 and SATA RAID 0/1/10. | |
| Ethernet | 1 x Realtek 2.5Gb Ethernet TUF LANGuard | |
| USB Rear | USB (Total 6 ports) 2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) Front USB (Total 7 ports) 1 x USB 3.2 Gen 1 (5G) connector (supports USB Type-C®) 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports | |
| Audio Realtek 7.1 Surround Sound High Definition Audio CODEC* - Supports: Jack-detection | Multi-streaming, Front Panel Jack-retasking - Supports up to 24-Bit/192 kHz playback Audio Features - Audio Shielding - Premium audio capacitors - Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output. | |
| Back Panel | I/O Ports 2 x USB 3.2 Gen 1 (5G) ports (2 x Type-A) 4 x USB 2.0 ports (4 x Type-A) 2 x DisplayPort 1 x HDMI™ port 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks 1 x BIOS FlashBack™ button 1 x PS/2 Keyboard/Mouse combo port | |
| Internal | I/O Connectors Fan and Cooling related 1 x 4-pin CPU Fan header 2 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V Power connector Storage related 2 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 3.2 Gen 1 (5G) connector (supports USB Type-C® ) 1 x USB 3.2 Gen 1 (5G) header supports 2 additional USB 3.2 Gen 1 ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x COM Port header 1 x Front Panel Audio header (AAFP) 1 x S/PDIF Out header 1 x Speaker header 1 x 10-1 pin System Panel header | |
| Special Features | ASUS TUF PROTECTION - DIGI+ VRM - ESD Guards - TUF LANGuard - Overvoltage Protection - SafeSlot Core+ - Stainless-Steel Back I/O ASUS Q-Design - M.2 Q-Latch - Q-DIMM - Q-LED Core - Q-Slot ASUS Thermal Solution - VRM heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED Aura Sync - Aura RGB header - Addressable Gen 2 headers | |
| Software Features | ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - Fan Xpert 2+ - Power Saving - Two-Way AI Noise Cancellation AI Suite 3 - TurboV EVO - DIGI+ VRM - PC Cleaner TUF GAMING CPU-Z Norton 360 for Gamers (60 Days Free Trial) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode | |
| BIOS 256 Mb Flash ROM | UEFI AMI BIOS | |
| Manageability WOL by PME | PXE | |
| Accessories Cables | 2 x SATA 6Gb/s cables Miscellaneous 1 x I/O Shield 1 x TUF Gaming sticker 1 x Screw package for M.2 SSD Documentation 1 x TUF Certification card 1 x User guide | |
| Operating System Windows® 11 | Windows® 10 64-bit | |
| Form Factor | Micro-ATX Form Factor 9.6 inch x 9.6 inch (24.4 cm x 24.4 cm) | |
| Warranty | 3 Years | |
| Note *** Features | Price, Specifications are subject to change without notice. |
Motherboard
| Brand | ASUS |
| Stock Status | IN STOCK |
| Chipset | A620 |
| Memory Type | DDR5 |
| Socket Support | AM5 |
| Form Factor | MICRO-ATX |
| Platform | AMD |
| Shipping Cost |
|
| Shop Location |
