Intel® H610 (LGA 1700) micro-ATX Motherboard

Name: Asus Prime H610M-CS DDR5 Gaming Motherboard
Brand: Brand
Price: 10000 INR
Availability: InStock
Rating: 5 (1 reviews)

The Intel® H610 (LGA 1700) micro-ATX motherboard is engineered to support the latest 12th Gen Intel® processors, providing a robust and versatile platform for modern computing needs. Designed with high-performance capabilities and enhanced durability, this motherboard is perfect for both professional and personal use. Let's delve into its key features and specifications:

Processor Support

Intel® LGA 1700 Socket: This motherboard is designed to accommodate 12th Gen Intel® Core™, Pentium® Gold, and Celeron® processors. The LGA 1700 socket ensures optimal compatibility and performance, enabling users to harness the full power of Intel's latest CPU architecture.

Cooling Solutions

Comprehensive Cooling: Equipped with a PCH heatsink, the motherboard efficiently dissipates heat, ensuring stable performance and longevity. The effective thermal management system keeps critical components cool under load, preventing overheating and maintaining optimal operation.

Connectivity Options

Ultrafast Connectivity: The motherboard features a high-speed 32Gbps M.2 slot, which supports the latest NVMe SSDs for rapid data transfer and reduced boot times. Additionally, it includes Realtek 1 Gb Ethernet for reliable wired network connections and multiple USB 3.2 Gen 1 ports for fast data transfer and peripheral connectivity.
- M.2 Slot: Provides up to 32Gbps data transfer speed, significantly enhancing system performance and responsiveness.
- Realtek 1 Gb Ethernet: Ensures stable and fast internet connectivity, suitable for both gaming and professional applications.
- USB 3.2 Gen 1 Ports: Multiple ports offer high-speed connectivity for a variety of peripherals, including external storage devices, keyboards, and mice.

Display and Expansion

Versatile Display Outputs: The motherboard is equipped with both HDMI® and D-Sub ports, allowing for flexible monitor connections. Whether you are using modern digital displays or older analog monitors, this motherboard has you covered.
- HDMI®: Supports high-definition video and audio output, ideal for modern monitors and TVs.
- D-Sub: Provides compatibility with older display technologies, ensuring versatility in display options.

Data and Storage

SATA 6 Gbps: Features multiple SATA ports supporting up to 6 Gbps data transfer rates, accommodating various storage devices such as SSDs and HDDs for expanded storage capacity and quick access to data.

Legacy and Additional Ports

Legacy Connectivity: The motherboard includes a COM header, LPT header, and TPM header, ensuring compatibility with older peripherals and enhancing security.
- COM Header: Supports legacy serial communication devices, often used in industrial and point-of-sale applications.
- LPT Header: Enables connectivity with legacy parallel port devices, ensuring support for older printers and other peripherals.
- TPM Header: Provides enhanced security through trusted platform module (TPM) support, ensuring data protection and secure boot.

Protection and Durability

5X Protection III: The motherboard features multiple hardware safeguards, including overvoltage protection, DIGI+ VRM, LANGuard, DRAM overcurrent protection, and stainless-steel back I/O, ensuring all-around protection and longevity.
- DIGI+ VRM: Provides precise power delivery to the CPU, enhancing stability and performance.
- LANGuard: Protects the Ethernet connection from power surges and static electricity.
- DRAM Overcurrent Protection: Prevents damage to the memory modules from excessive current.
- Stainless-Steel Back I/O: Resists corrosion and enhances durability.

Durable Design

Luminous Anti-Moisture Coating: A unique coating protects key components from moisture and corrosion, significantly extending the motherboard's lifespan and ensuring reliable performance in humid environments.

This motherboard combines state-of-the-art performance with reliable durability, making it an excellent choice for a wide range of users. Whether you are building a new system or upgrading an existing one, the Intel® H610 (LGA 1700) micro-ATX motherboard delivers the features and performance you need.

Intel® H610 (LGA 1700) micro-ATX Motherboard Specifications

CPU

Intel Socket LGA1700 for 12th Gen Intel Core, Pentium Gold, and Celeron Processors
Supports up to Intel 65W CPU
*Refer to www.asus.com for CPU support list

Chipset

Intel H610 Chipset

Memory

2x DIMM Max 64GB, DDR4 3200/3000/2933/2800/2666/2400/2133 Non-ECC, Un-buffered Memory*
Dual Channel Memory Architecture
Supports Intel® Extreme Memory Profile (XMP)
*Actual Memory data rate depends on the CPU types and DRAM modules, for more information refer to www.asus.com for memory support list.

Graphics

1x D-Sub
1x HDMI port
*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.

Expansion Slots

Intel® 12th Gen Processors
- 1 x PCIe 4.0 x16 slot
Intel H610 Chipset
- 1 x PCIe 3.0 x1 slot

Storage

Total supports 1 x M.2 slot and 4 x SATA 6Gb/s ports
Intel H610 Chipset
- M.2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 mode)
- 4 x SATA 6Gb/s ports

Ethernet

1 x Realtek 1Gb Ethernet

USB

Rear USB (Total 6 ports)

2x USB 3.2 Gen 1 ports (2x Type-A)
4x USB 2.0 ports (4x Type-A)

Front USB (Total 4 ports)

1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
1x USB 2.0 header supports additional 2 USB 2.0 ports

Audio

Realtek 7.1 Surround Sound High Definition Audio CODEC
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking
- Audio Shielding
- Supports up to 24-Bit/192 kHz playback
- Premium audio capacitors
- Dedicated audio PCB layers
*A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output
