Name: ASRock HVS/M.2 R2.0 H610M Gaming Motherboard
Brand: ASRock
Price: 5699 INR
Availability: InStock
Rating: 5 (1 reviews)

ASRock HVS/M.2 R2.0 H610M Gaming Motherboard

Reviews (0)

0 0 7

₹5,699 ₹11,999

-52%

Availability

In Stock

Product Code

H610M-HVS-M-2-R2-0

Brand

ASRock

Description

Let's break down the features of the ASRock H610M-HVS/M.2 R2.0 Motherboard:

Processor Compatibility: It supports 14th, 13th, and 12th Generation Intel Core processors with LGA1700 socket.

Power Phase Design: The motherboard boasts a 6+1+1 Phase Power Design, which can contribute to stable power delivery to the CPU, enhancing performance and overclocking capabilities.

Memory Support: It supports DDR4 memory with speeds up to 3200MHz, providing ample memory bandwidth for smooth multitasking and application performance.

Expansion Slots: It features 1 PCIe 4.0 x16 slot and 1 PCIe 3.0 x1 slot for adding additional components such as graphics cards or expansion cards.

Graphics Output: The motherboard offers graphics output options including HDMI and D-Sub, allowing you to connect various displays for visual output.

Audio Codec: It comes with a Realtek ALC897 7.1 Channel HD Audio Codec, providing high-quality audio output for immersive sound experiences.

Storage: The motherboard supports both PCIe Gen3 x4 Ultra M.2 interface and SATA3 6Gb/s M.2 modules, offering fast data transfer speeds and storage flexibility. It has 4 SATA3 ports and 1 Ultra M.2 slot.

USB Ports: It offers 4 USB 3.2 Gen1 ports (2 on the rear panel and 2 on the front panel) and 6 USB 2.0 ports (4 on the rear panel and 2 on the front panel), allowing you to connect various USB devices for data transfer or peripheral connectivity.

Networking: It features Realtek Gigabit LAN for high-speed wired network connectivity, facilitating smooth online experiences.

Overall, the ASRock H610M-HVS/M.2 R2.0 Motherboard offers a range of features and capabilities suitable for a variety of computing needs, especially with its support for the latest Intel Core processors and high-speed data transfer technologies.

Specification:

Model	H610M-HVS/M.2 R2.0
Unique Feature	ASRock Super Alloy Premium Power Choke Sapphire Black PCB High Density Glass Fabric PCB ASRock Ultra M.2 (PCIe Gen3x4) ASRock Full Spike Protection (for all USB, Audio, LAN Ports) ASRock Live Update & APP Shop
CPU	Supports 14th, 13th & 12th Gen Intel® Core™ Processors (LGA1700) 6+1+1 Power Phase design Supports Intel® Hybrid Technology Supports Intel® Turbo Boost Max 3.0 Technology
Chipset	Intel® H610
Memory	Dual Channel DDR4 Memory Technology 2 x DDR4 DIMM Slots Supports DDR4 non-ECC, un-buffered memory up to 3200 Supports ECC UDIMM memory modules (operate in non-ECC mode) Max. capacity of system memory: 64GB Supports Intel® Extreme Memory Profile (XMP) 2.0
BIOS	128Mb AMI UEFI Legal BIOS with multilingual GUI support ACPI 6.0 Compliant wake up events SMBIOS 2.7 Support CPU Core/Cache, CPU Core/Cache Load-Line, CPU GT, CPU GT Load-Line, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, +1.8V PROC, +1.05V PROC Voltage Multi-adjustment
Graphics	Intel® Xe Graphics Architecture (Gen 12) Dual graphics output: support HDMI and D-Sub ports by independent display controllers Supports HDMI 2.1 TMDS Compatible with max. resolution up to 4K x 2K (4096x2160) @ 60Hz Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible Port
Audio	7.1 CH HD Audio (Realtek ALC897 Audio Codec) Supports Surge Protection
LAN	PCIE x1 Gigabit LAN 10/100/1000 Mb/s 1 x Realtek RTL8111H Supports Wake-On-LAN Supports Lightning/ESD Protection Supports Energy Efficient Ethernet 802.3az Supports PXE
Slots	CPU: 1 x PCIe 4.0 x16 Slot (PCIE2), supports x16 mode* Chipset: 1 x PCIe 3.0 x1 Slot (PCIE1)
Storage	Chipset: 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2242/2260/2280 PCIe Gen3x4 (32 Gb/s) mode* 4 x SATA3 6.0 Gb/s Connectors
Connector	1 x SPI TPM Header 1 x Chassis Intrusion and Speaker Header 1 x CPU Fan Connector (4-pin)* 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)** 1 x 24 pin ATX Power Connector 1 x 8 pin 12V Power Connector 1 x Front Panel Audio Connector 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD Protection) 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports) (Supports ESD Protection)
Rear Panel I/O	1 x PS/2 Mouse/Keyboard Port 1 x D-Sub Port 1 x HDMI Port 2 x USB 3.2 Gen1 Ports (Supports ESD Protection) 4 x USB 2.0 Ports (Supports ESD Protection) 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) HD Audio Jacks: Line in / Front Speaker / Microphone
Software and UEFI	Software ASRock Motherboard Utility (A-Tuning) ASRock XFast LAN UEFI ASRock EZ Mode ASRock Full HD UEFI ASRock My Favorites in UEFI ASRock Instant Flash
Support CD	Drivers, Utilities, AntiVirus Software (Trial Version)
Accessories	Quick Installation Guide, Support CD, I/O Shield 2 x SATA Data Cables 1 x Screw for M.2 Socket
Hardware Monitor	Fan Tachometer: CPU, Chassis/Water Pump Fans Quiet Fan (Auto adjust chassis fan speed by CPU temperature): CPU, Chassis/Water Pump Fans Fan Multi-Speed Control: CPU, Chassis/Water Pump Fans CASE OPEN detection Voltage monitoring: CPU Vcore, DRAM, +0.82V PCH, +1.05V PCH, VCCIN AUX, VCCSA, +1.05V PROC, +12V, +5V, +3.3V
Form Factor	Micro ATX Form Factor: 8.66-in x 7.6-in, 22.0 cm x 19.3 cm Solid Capacitor design
OS	Microsoft® Windows® 10 64-bit / 11 64-bit
Certifications	FCC, CE ErP/EuP ready (ErP/EuP ready power supply is required)
Warranty	3 Years
Note	*** Features, Price, Specifications are subject to change without notice.
