The AX90 Black stands out with its distinctive mesh front panel design and exceptional cooling performance, making it a unique choice for gaming enthusiasts. The full-view tempered glass side panel not only adds a touch of elegance but also allows users to showcase their gaming setups without any hindrance. What sets the AX90 apart is its capacity to accommodate a remarkable 11 x 120mm fans simultaneously, ensuring powerful and efficient heat dissipation.
Key Features:
Unique Design & Powerful Heat Dissipation:
The AX90 boasts a unique mesh front panel design, optimizing cooling performance. The full-view tempered glass side panel complements this design, allowing users to display their gaming configurations seamlessly. The case supports an impressive 11 x 120mm fans for enhanced heat dissipation. Diamond-Shaped Mesh Front Panel:
The diamond-shaped mesh front panel is not just a design element; it is engineered to deliver massive airflow to the system while also incorporating a dust filtering function, keeping the internals clean. MAXIMUM COOLING POTENTIAL:
The spacious interior of the AX90 allows for the installation of both front and upper radiators up to 360mm, maximizing the cooling potential of the case. Powerful Cooling:
The case supports the side-mounting of either 1 x 240mm radiator or 2 x 120mm fans, providing additional options for powerful cooling configurations. High-Airflow Mesh Front Panel:
The enlarged mesh front panel ensures a high-flow path for air, contributing to the efficient cooling of internal components. Pre-Installed 4 x 120mm Fans:
The AX90 comes equipped with four pre-installed 120mm fans, effectively pulling in massive amounts of air for optimal cooling right out of the box. In Sync with Motherboard for ARGB Lighting:
The built-in control hub allows synchronization with the motherboard for ARGB lighting or manual control of ARGB lighting modes with the dedicated button, enabling users to create a personalized lighting setup. In summary, the AX90 Black combines a striking design with powerful cooling capabilities, making it an ideal choice for gamers seeking both aesthetics and performance. The mesh front panel, spacious interior, and ARGB lighting options make it a versatile case for enthusiasts looking to create a customized and visually appealing gaming setup.
| Specification | Details |
|---|---|
| Model | AX90 |
| Color | Black |
| Fan | |
| Dimensions | 473 x 210 x 486mm (DWH) |
| Form Factor | Mid Tower |
| Materials | Steel+Plastic |
| Mainboard Support | ATX, Micro-ATX, ITX |
| Front Access & Controls | Power, Reset, LED Control Button, 2 x USB 2.0, 1 x USB 3.0 , MIC / HD-AUDIO |
| Side Panel | 4MM Tempered glass |
| Drive Bays | |
| - Expansion Slots | 7 |
| - 3.5" / 2.5" | 2 / 1 |
| - 2.5" | 2 |
| Fan | |
| - Front | 3 x 120mm / 3 x 140mm |
| - Top | 3 x 120mm / 2 x 140mm |
| - Power supply | 2 x 120mm |
| - Side | 2 x 120mm |
| - Rear | 1 x 120mm |
| Included Fan(s) | 3 x 120mm ARGB fans in front + 1 x 120mm ARGB fan in rear |
| Radiator Support | |
| - Front | 120 / 140 / 240 / 280 / 360mm |
| - Top | 120 / 140 / 240 / 280 / 360mm |
| - Side | 120 / 240mm |
| - Rear | 120mm |
| Clearance | |
| - Max GPU Length | ≤ 385mm |
| - Max CPU Cooler Height | ≤ 160mm |
| - Max PSU Length | (Include cable) ≤ 220mm (with HDD), ≤ 410mm (without HDD) |
| Miscellaneous | |
| - Dust Filter | Front / Top / Bottom / Right Hand Side |
| Warranty | 1 Year |
| Note | *** Features, Price, Specifications are subject to change without notice. |
Case
| Brand | ANTEC |
| Stock Status | IN STOCK |
| Material | STEEL, PLASTIC |
| Cabinet Size | MID-TOWER |
| Motherboard Size | ATX |
| Motherboard Size | ITX |
| Motherboard Size | MATX |
| LED | ARGB |
| Fan Size | 120 MM |
| Radiator Support | 120 MM |
| Radiator Support | 140 MM |
| Radiator Support | 240 MM |
| Radiator Support | 280 MM |
| Radiator Support | 360 MM |
